What is load on a light switch

Load Wire: This is the wire that connects your switch to your light bulb or other “load” (ie: a fan or other appliance). It is also usually black. The Brilliant Control can automatically detect which wire is “Line” and which is “Load”, so they are interchangeable when installing in a single-pole configuration.

What does load mean on a light switch?

You might think of that as the “power line” side of the device. In electrical terms, a “load” is usually something like a light fixture, appliance, etc. that is actually using the electrical power. The “load” wires carry power from the switch or outlet to the load.

Does line and load matter on a light switch?

If you are speaking of a single pole switch, doesn’t matter. On a 2 pole switch, box mounted, technically it doesn’t matter, but good practices are line at the top, load at the bottom. If a disconnect switch, always line at the top, load at the bottom.

Which side of light switch is load?

Load Wire – Generally connected to the top half of your switch. If the wire is coming from the top of the switch box, it is likely your load wire. Line Wire – Generally connected to the bottom half of your switch. In some cases, line wires are marked with “line”, “pwr”, or a lightning bolt symbol.

What does load mean in electrical?

Load is the amount of electricity on the grid at any given time, as it makes its journey from the power source to all the homes, businesses and industries within a utility’s territory.

What color is load wire?

So, what color is the load wire? Load wires are mostly black, but red can also be used as a secondary load wire. They are also connected to the switch’s top half, while line wires are connected to the switch’s bottom half.

What is load and line?

In the electrical trades, the terms “line” and “load” are shorthand words that refer to the wires that deliver power from the source to a device (line), vs. those that carry power onward to other devices further along the circuit (load).

What is load and supply?

The supply goes to the power source. Load goes to whatever you turn on and off.

Is load or line the hot wire?

Line is the wire that goes from a source to a switch. It’s upstream of the switched device. Line is very hot. The wire from the switch to the device is called load.

What happens if you switch line and load wires?

Here’s what happens when somebody wires a GFCI receptacle with the load and line wires reversed: The GFCI will work, in the sense that you can plug in a hair dryer and the hair dryer will blow hot air. … If the load and line wiring gets messed up, a ground fault (radio in the tub) won’t trip the GFCI.

Article first time published on

What happens if you mix up line and load?

If you mistakenly connect the LINE wires to the LOAD terminals, the GFCI will not reset and will not provide power to either the GFCI receptacle face or any receptacles fed from the GFCI.

Which is line and load on outlet?

The “line” wires are the incoming power from the breaker box and the “load” wires are the outgoing power that travels down the circuit to the next outlet.

What happens if you wire a switch wrong?

This makes things like lamps and many appliances more safe to operate. But here’s the catch: If you connect the circuit wires to the wrong terminals on an outlet, the outlet will still work but the polarity will be backward. … The white (neutral) wire should be connected to the silver-colored terminal.

What is an example of a load in electricity?

An electrical load is simply any component of a circuit that consumes power or energy. In a household setting, the most obvious examples of electrical loads include light bulbs and appliances.

What does a load mean?

1 : something lifted up and carried : burden. 2 : the quantity of material put into a device at one time He washed a load of clothes. 3 : a large number or amount They collected loads of candy on Halloween. 4 : a mass or weight supported by something.

Is a switch a load in a circuit?

An electric switch is a device that interrupts the electron flow in a circuit. … Circuits consist of a source of power and load. A load is a power-powered device. The function of an electric switch is to regulate the current between the load and source of power.

What are load terminals?

The load terminals on a charge controller power connected DC devices. … Loads can be many things from a DC refrigerator to a DC LED light. Some loads should not be connected to the controller’s load terminals and instead connected directly to the battery.

Is load the same as neutral?

Line wires comprise three wires that stand for hot, neutral both are insulated and ground bare wire. While load wires are wires that transmit electricity from the electrical device to other devices within the building, load wires are also known as outgoing or downstream wires.

What is load and feed on a switch?

The feed is the cable from your fuse board, supplying the power to the isolator switch. The load is the cable supplying the appliance once you have switched the isolator into the on position.

Is load an input or output?

The source/input terminal is where power enters the circuit. Note that the input to a circuit can be the output from another circuit. The load/output terminal is where power leaves the circuit. It is where the load (load is anything that uses the output for any operation) is connected to the circuit.

Will a light switch work if wired backwards?

A light switch is a simple device with only two states, competing a circuit (On) or breaking a circuit (Off). It is a series control element is a series – parallel circuit design. A light switch has no polarization so when you reverse the connections on the light switch it works just as before you reversed the wires.

Which wire is hot if both are black?

The black wire is the “hot” wire, it carries the electricity from the breaker panel into the switch or light source. The white wire is the “neutral” wire, it takes any unused electricity and current and sends it back to the breaker panel.

What happens if you wire a outlet backwards?

If your outlet’s polarity is reversed, it means that the neutral wire is connected to where the hot wire is supposed to be. … There is always electricity flowing out of an outlet with reversed polarity, even if an appliance is supposed to be off.

What color is the common wire on a light switch?

Red, Black, and White are the colors of switch wiring for three-ways. Red and Black are connected to the switches if the White is used for neutral. The White is often referred to as Common, but the colored wires are also used as hot wires.

Why does my light switch have 2 black wires?

You should see two black wires, each connecting to a different screw on the side of the switch. These are called terminal screws. … These are ground wires.
